configure macsec mka actor-priority

configure macsec mka actor-priority actor_priority ports port_list

Description

Configures MAC Security (MACsec) actor‘s priority for port(s).

Syntax Description


mka	Configures MACsec key agreement (MKA) parameters.
actor-priority	Designates setting the priority advertised during MKA key server election.
`actor-priority`	Sets the actor priority value. A lower value denotes higher priority.Range is 0–255 or 0x0–0xFF. Default is 0x10.
ports	Specifies configuring ports.
`port_list`	Lists which ports to configure the actor priority on.

Default

Default value for actor priority is 0x10.

Usage Guidelines

Each MKA participant selects the participant advertising the highest priority as the key server. In the event of a tie, the participant with the highest priority MAC address (lowest value) is selected. The recommended priority range for infrastructure ports is 0x00 to 0x1f, with a default of 0x10. You can assign the full range of priorities, 0x00 to 0xff:

To have a port become a key server, raise the priority by assigning a priority value less than 0x10.
To not have a port become key server, lower the priority by assigning a priority value greater than 0x10.

Important

After enabling MACsec, if you change the actor priority, you must run the configure macsec initialize ports port_list command afterward. Otherwise, the change is not applied.

Example

The following example raises the actor priority value to 0x5 on port 13:

# configure macsec mka actor-priority "0x5" port 13
# configure macsec initialize port 13

The following example lowers the actor priority value to "31" on port 14:

# configure macsec mka actor-priority 31 port 14
# configure macsec initialize port 14

History

This command was first available in ExtremeXOS 30.1.

Platform Availability

This command is available on the following platforms.

Note

The MACsec feature requires the installation of the MAC Security feature pack license.


Platform	Ports
ExtremeSwitching 5320	All ports of all models except stacking ports.
ExtremeSwitching 5420	All ports of all models except stacking ports.
ExtremeSwitching 5520	All ports, except 5520-VIM-4X and 5520-24X 10G ports
ExtremeSwitching 5720	All ports of all models except stacking ports.
Extreme 7520-48YE-8CE	All front-panel ports.
